Project Monitoring: Grad. Eng. Jens Neugebauer

Particle Image Velocity System

The ISMT operates a stereoscopic Particle-Image-Velocimetry System (PIV-System) for the non-intrusive measurement of velocities in three components within a measurement plane. The advantage of using PIV compared to a 5-Hole-Sensor or Laser-Doppler-Anemometry (LDA) is the simultaneous acquisition of velocities in the desired plane, while the other techniques require a repositioning of the measurement device. Furthermore, compared to the 5-Hole-Sensor, the advantage of PIV is also its non-intrusiveness.

more aboutParticle Image Velocity System

Server room
Server room

Data Processors at the ISMT

Hardware

  • CFD processor cluster with 44 processors and 752 processor cores
  • seminar processor cluster with LINUX and WINDOWS system software

Software

  • CFD/FEM

         OpenFOAM, STARCCM+, Ansys, Comet, Poseidon, Pro-E, Uthlande, Friendship

  • MATH.CAS

          Matlab

  • CAD-2D-3D
  • OFFICE
